Pilot RC - FC1 3D Elster Jet 120" (3.05M) ARF Kit Turbine Ready With Retracts (Version 3)
Pilot-RC
PILFC1120V3
Artikel auf Bestellung beim Lieferanten
Dieser Artikel ist nicht vorrätig; er wird für Sie bei unserem Lieferanten bestellt. Die Lieferzeit hängt von der Verfügbarkeit beim Lieferanten ab.
€ 6.599,00€ 5.453,72 excl. Mwst.
Pilot-RC is very proud to announce a new collaboration with the undisputed pioneers of 3D jet flying and designers of that very first 3D J10, Ralph and Enrico from Elster Jet.
This new collaboration has led to Pilot-RC to produce their latest design, the FC1.
Designed to be both precise and highly capable in normal aerobatics and also extremely agile and light for 3D flying. Elster’s background in 3D jet flying has led to a number of innovative solutions that assure a light, strong and extremely capable and fun new aircraft to fly.
Please note : This kit is version 3 and includes a UAT, fuel tank, Vector thrust pipe, fuel dot, fuel tank vent, hardware. Electric retract gear with brake. Servos, smoke system with smoke pump/smoke tank. Wing bag. preinstall the above items in factory.
SPECIFICATIONS:
Model:
FC1
Wingspan:
74.8″ (1,900mm)
Length:
120″ (3,055mm)
Wing area:
1,734″2 (11,190cm2)
Weight:
31-32.5lbs (14-14.7kg) with JetCat P220Rxi turbine and full UAT
FEATURES:
German design, by Ralph and Enrico from Elster Jet, designers of the first J10’s
Extremely lightweight full composite construction especially designed for outstanding 3D performance
Painted outside the mold so no seam lines
Ultra strong and light weight landing gear mounts, with factory installed blind nuts so mounting is just plug and play
Split fuselage design is joined with 5 screws, with only batteries and nose gear installed in the front section, meaning very easy connections and quick assembly at the field
Specially designed easy access to turbine for speedy installation
Wings and elevator are secured from the top
Removable wing and elevator for easy transport
Please note that the FC1 is designed specifically for aerobatics and 3D vectored flight, with light weight being key. It is not designed to be used as a full power, high speed race plane.
INCLUDED HARDWARE:
Complete air frame (including carbon wing-tubes and preinstalled and painted fibreglass control horns)
Servo extension leads
Vector thrust pipe
4.500ml fuel tank
250ml UAT tank
Pre-prepared pushrods with ball links
REQUIRED HARDWARE:
Turbine 140-190N for normal sport flying
Turbine 200-260N for 3D vector flight – Avoid high speed, high G flying
Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories.
Available and orderable in 3 versions and all the schemes shown in the pictures.
Without gear combo (Version 1) :
Pilot-RC FC1 kit
Requires servos and turbine of choice.
Include vector thrust pipe
Landing gear combo (Version 2) :
Pilot-RC FC1 kit
Pilot-RC electric landing gear & brakes set
Requires servos and turbine of choice.
Include vector thrust pipe
Turbine Ready Combo (Version 3) :
Pilot-RC FC1 kit
Pilot-RC electric landing gear & brakes set installed
Pilot-RC servos and extension wires, all installed
Standard dual wall thrust pipe, UAT, fuel tank, fuel dot, fuel tank vent, all installed
