Pilot RC - FC1 3D Elster Jet 85" (2.20M) ARF Kit Without Retracts (Version 1)
Pilot-RC
PILFC185V1
Artikel auf Bestellung beim Lieferanten
Dieser Artikel ist nicht vorrätig; er wird für Sie bei unserem Lieferanten bestellt. Die Lieferzeit hängt von der Verfügbarkeit beim Lieferanten ab.
€ 2.799,00€ 2.313,22 excl. Mwst.
Following the great success and feedback from our large FC1, we have continued our collaboration with Ralph & Enrico from Elster Jet to produce a smaller, more everyday and easy to transport version, sized around the most popular turbines and without compromising on performance.
Please note : This kit is version 1 and includes a UAT, fuel tank, Vector thrust pipe, fuel dot, fuel tank vent, servo extension wire, hardware. Without retract gear
SPECIFICATIONS:
Model:
FC1
Wingspan:
52.3″ (1,329mm)
Length:
85.4″ (2,169mm)
Wing area:
NO
Weight:
19.6lbs (8.9kg) with JetCat P130Rxi turbine and fuel bag
FEATURES:
German design, by Ralph and Enrico from Elster Jet
Extremely lightweight full composite construction especially designed for outstanding 3D performance
Painted outside the mold so no seam lines
Ultra strong and light weight landing gear mounts, with factory installed blind nuts so mounting is just plug and play
Specially designed easy access to turbine for speedy installation
Field setup can be done in seconds, thanks to the quick releases on the wings without the need for any tools, and the single elevator bolt accessed from the side
Removable wing and elevator for easy transport
Please note that the FC1 is designed specifically for aerobatics and 3D vectored flight, with light weight being key. It is not designed to be used as a full power, high speed race plane.
INCLUDED HARDWARE:
Complete air frame (including carbon wing-tubes and preinstalled and painted fibreglass control horns)
Servo extension leads
Vector thrust pipe
3.600ml fuel tank (optional upgrade to fuel bag)
250ml UAT tank
Pre-prepared pushrods with ball links
REQUIRED HARDWARE:
Turbine 80-140N for normal sport flying
Turbine 160-180N for 3D vector flight – Avoid high speed, high G flying
Servos: Total x10 (x5 standard size + x5 medium size)
x3 standard size high torque
x2 for flaps (minimum 40kg)
x1 for rudder (minimum 40kg)
x7 medium size servo for steering (size: 35x15x30mm)
x2 for ailerons (minimum 16kg)
x2 for elevators (minimum 16kg)
x1 for vector elevator (minimum 16kg)
x1 for vector rudder (minimum 16kg)
x1 for steering (minimum 10kg)
Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories.
Available and orderable in 3 versions and all the schemes shown in the pictures.
Without gear combo (Version 1) :
Pilot-RC FC1 kit
Requires servos and turbine of choice.
Include vector thrust pipe
Landing gear combo (Version 2) :
Pilot-RC FC1 kit
Pilot-RC electric landing gear & brakes set
Requires servos and turbine of choice.
Include vector thrust pipe
Turbine Ready Combo (Version 3) :
Pilot-RC FC1 kit
Pilot-RC electric landing gear & brakes set installed
Pilot-RC servos and extension wires, all installed
Standard dual wall thrust pipe, UAT, fuel tank, fuel dot, fuel tank vent, all installed
Requires your own turbine of choice.
Include vector thrust pipe
General Info
Brand
Pilot-RC
Item Nr
PILFC185V1
Airplane - Specs
Material
Full composite
Wingspan (mm)
1329
Model Length (mm)
2169
Take-off Weight (g)
8900
Airplane - Functions
Controls
Motor
Retractable Landing Gear
Rudder
Ailerons
Elevator
Flaps
Required Radio (Not included)
Min. 8 Channel
Airplane - Power System
Power System
Not Included (See Needed to complete)
Airplane - Electronics
Receiver
Not Included
Qty of Servos
10x Servos | (Not Included | See Needed to complete)
