AXI 2814/16 V2 Brushless Motor

AXI 2814/16 V2 Brushless Motor

AXI model motors

3EL105321V2

not in stock

€ 103,59 € 85,61 excl. VAT

Powering LiXX cells	3S
RPM/V [ot./min/V]	1035
Turn count	16
Internal resistance [mOhm]	85
Open-circuit current [A]	1
Max. efficiency [%]	84
Max. efficiency current (η>75%) [A]	12 - 20
Max. peak current (60 s) [A]	32
Max. power [W]	325
Diameter [mm]	35
Length [mm]	37.5
Shaft diameter [mm]	5
Weight [g]	107
Poles count	14
Timing [°]	15 - 25
ESC [A]	35 - 45
Weight of glider (up-to) [g]	1700
Weight of trainer (up-to) [g]	1600
Weight of acrobat (up-to) [g]	1400
Weight of 3D (up-to) [g]	1100

General Info

Brand: AXI model motors

Barcode: 8595247302229,00

Motor - Specs

Motor - Input Voltage Range (V): 3S Li-Po

Motor - KV (Rpm/V): 1035,00

Motor - Poles: 14-Pole

Motor - Timing: 15-25

Motor - Turns (T): 16,00

Motor - Dimensions

Motor - Dia. ø (mm): 35,00

Motor - Length (mm): 37,50

Motor - Shaft Dia. ø (mm): 5.0 mm

Motor - Weight (g): 107,00
